The Kugel Komponents 3/16" x 3/16" Double Line Clamps (6-Pack) offer a clean, professional, and symmetrical plumbing solution for your vehicle. Designed to secure two identical small-diameter lines running perfectly parallel along your frame rails, firewalls, or undercarriages, these dual-opening clamps allow you to consolidate your routing into a single mounting point for a show-quality finish.
Ideal Symmetrical Routing Applications
The dual 3/16" configuration is custom-engineered for handling twin small-diameter lines safely and neatly:
-
Dual Hard Brake Lines: Ideal for routing front-to-rear brake lines alongside independent circuit lines, or managing split brake lines heading out from a proportioning valve or master cylinder.
-
Small Vacuum or Air Suspension Lines: Perfect for running dual 3/16" O.D. hard-line pneumatic lines or mechanical gauge lines side-by-side.
By locking parallel lines into a single, rigid stainless steel clamp, you preserve exact line spacing. This eliminates metal-to-metal rubbing, preventing dangerous friction wear and annoying harmonic chassis rattles.
Precision Sizing and Versatility
Kugel Komponents sizes these clamps by their exact Inside Diameter (I.D.), which directly corresponds to the Outside Diameter (O.D.) of the lines you need to secure. Whatever the total O.D. of your line, hose, or cable is—that is the exact clamp size required.
To help plan the rest of your vehicle layout, refer to this quick reference guide for other popular automotive hose and cable dimensions:
-
-3 AN Stainless Braided Hose 1/4″ Clamp
-
-4 AN Stainless Braided Hose 5/16″ Clamp
-
-6 AN Stainless Braided Hose / Most Battery Cables 1/2″ Clamp
-
-8 AN Stainless Braided Hose / 3/8″ Rubber Fuel Line 5/8″ Clamp
-
-10 AN Stainless Braided Hose 3/4″ Clamp
-
-12 AN Stainless Braided Hose / 5/8″ Heater Hose 7/8″ Clamp
Premium Construction
-
Heavy-Gauge Stainless Steel: Stamped from premium, corrosion-resistant stainless steel that handles extreme under-car environments without rusting, pitting, or losing its finish.
-
Low-Profile Allen Hardware: Each kit comes complete with 10/32 stainless steel button head Allen screws, providing a sleek, snag-free flush mount when torqued down against your chassis.
Technical Summary
| Feature |
Detail |
| Clamp Combo Sizes (I.D.) |
Twin Symmetrical 3/16" Openings |
| Primary Application |
Parallel Routing for Dual Brake Lines or Vacuum Lines |
| Material |
Heavy-Gauge Stainless Steel |
| Pack Quantity |
6 Clamps & 6 Screws |
| Hardware Thread Size |
10/32" |
| Hardware Style |
Button Head Allen Drive |
Installation Tip
To mount these dual-line clamps, you will need to drill and tap your chosen mounting surface for a 10/32 thread. Because you are securing two fluid lines under a single fastener, applying a drop of medium-strength blue threadlocker to each screw is highly recommended to protect against road vibrations and ensure your plumbing remains safely locked down.
