Dakota Digital Series III instrument systems offer the latest technologies and features for your custom vehicle. High brightness vacuum fluorescent displays provide a lifetime of trouble free use while offering increased accuracy and features!
Full 6 Gauge Instrument System fits into OEM bezel for 1970- 72 non SS Chevy Chevelle, Malibu and El Camino.
Fits directly into existing bezel (not included).
*No longer requires the stock gauge cluster to be sent in to Dakota Digital*
Digital Gauges
Speedometer
·0 -255 MPH (optional metric version 0- 255 km/h)
Tachometer
·0- 17,500 RPM
Oil Pressure
·0- 99 psi
Water Temperature
·0- 300ºF (optional metric version 0- 150ºC)
Fuel Level
·0- 99%
Voltmeter
·8- 17 VDC
Standard Colors
·Blue or Teal
Digital Message Centers
Standard Displays
·Odometer (One time user settable, Million Mile)
·Dual (A/B) Trip Meter (0- 9,999.9)
Performance Meters
·0- 60 MPH Timer (0- 100 kmh)
·1/4 mile time
·1/4 mile end speed (trap speed)
·High speed recall
·High RPM recall
Gauges
·Speedometer (0- 255 MPH/kmh) opposite scale of main speedometer.
Indicators
·Turn Signals (Left/ Right)
·High Beam
·Check Engine
·Parking Brake
·Cruise Control (On/ On & Engaged when vehicle is equipped)
·Gear Position (Optional GSS-3000 sensor required)
·4 x 4 (When vehicle is equipped)
·Wait to Start (When vehicle is equipped)
